Senasys 358 Series Remote Sensing Thermostat Cross Reference is a single stage, direct replacement option to many other capillary thermostats found on the market today. With competitive pricing, faster lead times and our ability to customize our thermostats to meet your application requirements, we are sure to be a top producer of the bulb & capillary thermostats on the market today! Check out our 358 Series remote sensing thermostat cross reference guide below.
As an easy guide for you we have created this simple cross reference guide to help you find the replacement capillary thermostat you need. If you have one of the series listed below, simply match it to our series. Give us a call for more information.
Benefits of Choosing Senasys 358 Series
- Widest temperature calibration range available on the market.
- UL/cUL Rated for 100,000 cycles at 25A @ 250VAC.
- Senasys bulb & capillary thermostats are designed & manufactured in Eau Claire, WI, U.S.A.
Senasys designs and manufactures bulb & capillary thermostats. Senasys switches are UL/cUL Recognized. All switches are made in the United States and our direct customer service would be happy to help you find the right switch for your application.
These cost-effective thermostats are produced to exacting standards to meet the needs of original equipment manufacturers and instrument makers for a low cost, stable, repeatable switch.
Multiple mounting options, terminals, and temperatures are available. Please contact us with your application requirements for availability.
Applications
The 358 Series Remote Sensing thermostat is commonly found in HVAC and food equipment used as a limit or control device when temperatures exceed the defined preset temperature. See how capillary thermostats are used in everyday applications by clicking here!
Can’t find your part number listed? Give our direct support a call with your switch or application requirements and one of our customer service representatives will assist you!
358 Remote Sensing Thermostat Cross Reference
Find your replacement thermostat using the cross-reference guide below, or download the PDF document here. For further assistance, contact our support team.
| Senasys | E.G.O. | |
| 354 Series | EF Series | |
| Temperature Range | -40°F to 675°F | -31°F – 932°F |
| Temperature Setting | Adjustable or Fixed | Adjustable or Fixed |
| Adjustment Options | D-Shaft Adjustment Knobs | D-Shaft Adjustment Knobs |
| Maximum Ambient Temperature | 250°F | 250°F |
| Reset Type | Automatic | Automatic or Manual |
| Number of Stages | Single | Single, Two or Three |
| Terminal Options | Screw, with Wire Leads Available | Screw |
| Amperage | 25 Amps | 16 Amps |
| Voltage | 250VAC | 250VAC |
| Cycle Life | 100,000 | 100,000 |
| Material Options | Copper, Dull-Nickel Plated Copper, One-Piece Stainless Steel, or Two-Piece Stainless Steel | Copper or Stainless Steel |
| Approvals | UL / cUL | UL / cUL |
| Origin | USA | Germany |
